Chicken Manure Dryer

Chicken Manure Dryer

Chicken manure dryer is suitable to be used in large, medium and small-sized chicken house and the areas where the breeding industry is developed.
Email: vip@sinoftm.com

Features

Chicken manure dryer is suitable to be used in large, medium and small-sized chicken house and the areas where the breeding industry is developed. According to the requirement of the drying products, different heat sources can be used.

Chicken manure dryer, cow dung dryer, pig manure dryer and other animal wastes dryer can directly dry animal dung with the water content as high as 70%-80% to the safe moisture content of 13% for one time for the convenience of the production of organic fertilizer. The whole drying process is completed in a closed system, which can reduce the pollution to the environment in the drying process.

Chicken manure dryer

Animal wastes dryer, like cow dung dryer and pig manure dryer, is composed of hot blast heater, conveying device, feeding device, rotary crushing and dryer, transmission device, electric system, discharging device, dust collecting device and purging system.

Chicken manure dryer is applied to drying chicken manure, as well as cow dung, sheep manure and other animal waste. The animal wastes dryer, like cow dung dryer and pig manure dryer, can be used in large-scale farm or medium-sized farm. As a kind of new drying equipment, the fertilizer granulation equipment is essential in the production of compound fertilizer.

Technical data

Spec./m
(Dia.×Length)
Shell Cubage
(m³)
Capacity
(t/h)
Installation
Obliquity
(%)
Highest Inlet
Air Temperature
(℃)
Main Motor
(kw)
Weight
(t)
Φ1.2×8.0
9.0
1.9~2.4
3~5
700~800
7.5
9
Φ1.2×10
11.3
2.4~3.0
3~5
700~800
7.5
11
Φ1.5×12
21.2
4.5~5.7
3~5
700~800
15
18.5
Φ1.5×14
24.7
5.3~6.6
3~5
700~800
15
19.7
Φ1.5×15
26.5
5.7~7.1
3~5
700~800
15
20.5
Φ1.8×12
30.5
6.5~8.1
3~5
700~800
18.5
21.5
Φ1.8×14
35.6
7.6~9.5
3~5
700~800
18.5
23
Φ2.2×12
45.6
9.7~12.2
3~5
700~800
22
33.5
Φ2.2×14
53.2
11.4~14.2
3~5
700~800
22
36
Φ2.2×16
60.8
13.0~16.2
3~5
700~800
22
38
Φ2.4×14
63.3
13.5~16.9
3~5

700~800
37
45
Φ2.4×18
81.4
17.4~21.7
3~5
700~800
37
49
Φ2.4×20
90.4
19.3~24.1
3~5
700~800
45
54
Φ2.4×22
99.5
21.2~26.5
3~5
700~800
45
58
Φ2.6×24
127.4
27.2~34.0
3~5
700~800
55
73
Φ3.0×20
141.3
30.1~37.7
3~5
700~800
75
85
Φ3.0×25
176.6
37.7~47.1
3~5
700~800
75
95
Φ3.2×25
201
42.9~53.6
3~5
700~800
90
110
Φ3.6×28
285
60.8~76.0
3~5
700~800
160
135

Technical parameters of indirect heat dryer:

  Shell
diameter
×shell
Length
Items
Inside
diameter
of outer
shell
(mm)
Inside
diameter
of inner
shell
(mm)
Shell
 Length
(m)
Shell
 cubage
(m³)
Shell
obliquity
Lifting
blade
 form
Highest
inlet air
 temperature
(℃)
Dimensions
(m)
Φ1.5×15m 1500 500 15 20.27 3-5% Lifting form 850 16.2×2.7×2.7
Φ1.5×17m 17 22.97 18.2×2.7×2.7
Φ1.5×19m 19 25.68 20.0×2.9×2.9
Φ1.8×21m 1800 650 21 35.91 3-5% Lifting form 850 22.5×2.7×2.7
Φ1.8×23m 23 39.33 24.5×2.9×2.9
Φ1.8×25m 25 42.75 26.5×2.9×2.9
Φ2.2×21m 2200 800 21 58.10 3-5% Lifting form 850 ----
Φ2.2×23m 23 63.61
Φ2.2×25m 25 69.15
